NTTFS008P03P8Z Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (3.3x3.3)
- Description: MOSFET P-CH 30V 22A/96A 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS008P03P8Z Specifications:
- MfrPart.: NTTFS008P03P8Z
- Mfr: onsemi
- Description: MOSFET P-CH 30V 22A/96A 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 22A (Ta), 96A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.8mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 134 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 5600 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.36W (Ta), 50W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (3.3x3.3)
- NTTFS008P03P8Z onsemi (ON), MOSFET P-CH 30V 22A/96A 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
