NTS2101PT1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-70-3 (SOT323)
- Description: MOSFET P-CH 8V 1.4A SC70-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTS2101PT1 Specifications:
- MfrPart.: NTS2101PT1
- Mfr: onsemi
- Description: MOSFET P-CH 8V 1.4A SC70-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 8 V
- Current-ContinuousDrain(Id)@25°C: 1.4A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 100mOhm @ 1A, 4.5V
- Vgs(th)(Max)@Id: 700mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 6.4 nC @ 5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 640 pF @ 8 V
- FETFeature: -
- PowerDissipation(Max): 290mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70-3 (SOT323)
- NTS2101PT1 onsemi (ON), MOSFET P-CH 8V 1.4A SC70-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
