NTR1P02T3G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
- Description: MOSFET P-CH 20V 1A SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTR1P02T3G Specifications:
- MfrPart.: NTR1P02T3G
- Mfr: onsemi
- Description: MOSFET P-CH 20V 1A SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 1A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 180mOhm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 2.3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 2.5 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 165 pF @ 5 V
- FETFeature: -
- PowerDissipation(Max): 400mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3 (TO-236)
- NTR1P02T3G onsemi (ON), MOSFET P-CH 20V 1A SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTR1P02T3G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
