NTP5D0N15MC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220
- Description: MOSFET N-CH 150V 15A/139A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTP5D0N15MC Specifications:
- MfrPart.: NTP5D0N15MC
- Mfr: onsemi
- Description: MOSFET N-CH 150V 15A/139A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 15A (Ta), 139A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 5mOhm @ 97A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 532µA
- GateCharge(Qg)(Max)@Vgs: 75 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6300 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 2.4W (Ta), 214W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220
- NTP5D0N15MC onsemi (ON), MOSFET N-CH 150V 15A/139A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTP5D0N15MC, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
