NTP45N06LG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220
- Description: MOSFET N-CH 60V 45A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTP45N06LG Specifications:
- MfrPart.: NTP45N06LG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 45A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 45A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 28mOhm @ 22.5A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 32 nC @ 5 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 1700 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.4W (Ta), 125W (Tj)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220
- NTP45N06LG onsemi (ON), MOSFET N-CH 60V 45A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
