NTP125N02R Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET N-CH 24V 95A/120.5A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTP125N02R Specifications:
- MfrPart.: NTP125N02R
- Mfr: onsemi
- Description: MOSFET N-CH 24V 95A/120.5A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 24 V
- Current-ContinuousDrain(Id)@25°C: 95A (Ta), 120.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 4.6mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 28 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3440 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 1.98W (Ta), 113.6W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- NTP125N02R onsemi (ON), MOSFET N-CH 24V 95A/120.5A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
