NTMYS4D1N06CLTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 4-LFPAK
- Description: MOSFET N-CH 60V 22A/100A LFPAK4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMYS4D1N06CLTWG Specifications:
- MfrPart.: NTMYS4D1N06CLTWG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 22A/100A LFPAK4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 22A (Ta), 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 4mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 2V @ 80µA
- GateCharge(Qg)(Max)@Vgs: 34 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2200 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.7W (Ta), 79W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 4-LFPAK
- NTMYS4D1N06CLTWG onsemi (ON), MOSFET N-CH 60V 22A/100A LFPAK4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMYS4D1N06CLTWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
