NTMSD6N303R2G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 6A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMSD6N303R2G Specifications:
- MfrPart.: NTMSD6N303R2G
- Mfr: onsemi
- Description: MOSFET N-CH 30V 6A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: FETKY™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 32mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 30 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 950 pF @ 24 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- NTMSD6N303R2G onsemi (ON), MOSFET N-CH 30V 6A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMSD6N303R2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
