NTMS5P02R2SG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET P-CH 20V 3.95A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMS5P02R2SG Specifications:
- MfrPart.: NTMS5P02R2SG
- Mfr: onsemi
- Description: MOSFET P-CH 20V 3.95A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.95A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 33mOhm @ 5.4A, 4.5V
- Vgs(th)(Max)@Id: 1.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 4.5 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 1.9 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 790mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- NTMS5P02R2SG onsemi (ON), MOSFET P-CH 20V 3.95A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMS5P02R2SG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
