NTMS4N01R2 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 20V 3.3A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMS4N01R2 Specifications:
- MfrPart.: NTMS4N01R2
- Mfr: onsemi
- Description: MOSFET N-CH 20V 3.3A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.3A (Tj)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 40mOhm @ 4.2A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 16 nC @ 4.5 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 1200 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 770mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- NTMS4N01R2 onsemi (ON), MOSFET N-CH 20V 3.3A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMS4N01R2, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
