NTMS4700NR2 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 8.6A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMS4700NR2 Specifications:
- MfrPart.: NTMS4700NR2
- Mfr: onsemi
- Description: MOSFET N-CH 30V 8.6A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 8.6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 7.2mOhm @ 13A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 24 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1.6 pF @ 24 V
- FETFeature: -
- PowerDissipation(Max): 860mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- NTMS4700NR2 onsemi (ON), MOSFET N-CH 30V 8.6A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMS4700NR2, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
