NTMS4101PR2 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET P-CH 20V 6.9A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMS4101PR2 Specifications:
- MfrPart.: NTMS4101PR2
- Mfr: onsemi
- Description: MOSFET P-CH 20V 6.9A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 6.9A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 19mOhm @ 6.9A, 4.5V
- Vgs(th)(Max)@Id: 450mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 32 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 3200 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1.38W (Tj)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- NTMS4101PR2 onsemi (ON), MOSFET P-CH 20V 6.9A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
