NTMJS0D9N04CTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-LFPAK
- Description: MOSFET N-CH 40V 52A/342A 8LFPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMJS0D9N04CTWG Specifications:
- MfrPart.: NTMJS0D9N04CTWG
- Mfr: onsemi
- Description: MOSFET N-CH 40V 52A/342A 8LFPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 52A (Ta), 342A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 810µOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 117 nC @ 10 V
- Vgs(Max): 20V
- InputCapacitance(Ciss)(Max)@Vds: 7400 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 4.2W (Ta), 180W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-LFPAK
- NTMJS0D9N04CTWG onsemi (ON), MOSFET N-CH 40V 52A/342A 8LFPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
