NTMFS7D8N10GTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (5x6)
- Description: N-CHANNEL SHIELDED GATE POWERTRE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS7D8N10GTWG Specifications:
- MfrPart.: NTMFS7D8N10GTWG
- Mfr: onsemi
- Description: N-CHANNEL SHIELDED GATE POWERTRE
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 14A (Ta), 110A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 7.6mOhm @ 48A, 10V
- Vgs(th)(Max)@Id: 4V @ 254µA
- GateCharge(Qg)(Max)@Vgs: 92 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6180 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 187W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (5x6)
- NTMFS7D8N10GTWG onsemi (ON), N-CHANNEL SHIELDED GATE POWERTRE, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
