NTMFS6H818NLT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 80V 22A/135A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS6H818NLT1G Specifications:
- MfrPart.: NTMFS6H818NLT1G
- Mfr: onsemi
- Description: MOSFET N-CH 80V 22A/135A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 22A (Ta), 135A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.2mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2V @ 190µA
- GateCharge(Qg)(Max)@Vgs: 64 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3844 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 3.8W (Ta), 140W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS6H818NLT1G onsemi (ON), MOSFET N-CH 80V 22A/135A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMFS6H818NLT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
