NTMFS4825NFET1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 30V 17A/171A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS4825NFET1G Specifications:
- MfrPart.: NTMFS4825NFET1G
- Mfr: onsemi
- Description: MOSFET N-CH 30V 17A/171A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 17A (Ta), 171A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2mOhm @ 22A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 40.2 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5660 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 950mW (Ta), 96.2W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS4825NFET1G onsemi (ON), MOSFET N-CH 30V 17A/171A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
