NTMFS1D7N03CGT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET, POWER, 30V N-CHANNEL, SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS1D7N03CGT1G Specifications:
- MfrPart.: NTMFS1D7N03CGT1G
- Mfr: onsemi
- Description: MOSFET, POWER, 30V N-CHANNEL, SO
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 35A (Ta), 170A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.74mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 90µA
- GateCharge(Qg)(Max)@Vgs: 48 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3780 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 3.8W (Ta), 87W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS1D7N03CGT1G onsemi (ON), MOSFET, POWER, 30V N-CHANNEL, SO, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
