NTMFS0D8N02P1ET1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 25V 55A/365A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS0D8N02P1ET1G Specifications:
- MfrPart.: NTMFS0D8N02P1ET1G
- Mfr: onsemi
- Description: MOSFET N-CH 25V 55A/365A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 55A (Ta), 365A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 680µOhm @ 46A, 10V
- Vgs(th)(Max)@Id: 2V @ 2mA
- GateCharge(Qg)(Max)@Vgs: 52 nC @ 4.5 V
- Vgs(Max): +16V, -12V
- InputCapacitance(Ciss)(Max)@Vds: 8600 pF @ 13 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 139W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS0D8N02P1ET1G onsemi (ON), MOSFET N-CH 25V 55A/365A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
