NTMFS022N15MC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (5x6)
- Description: POWER MOSFET, 150V SINGLE N CHAN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS022N15MC Specifications:
- MfrPart.: NTMFS022N15MC
- Mfr: onsemi
- Description: POWER MOSFET, 150V SINGLE N CHAN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 7.3A (Ta), 41.9A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 8V, 10V
- RdsOn(Max)@IdVgs: 22mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1315 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 80.6W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (5x6)
- NTMFS022N15MC onsemi (ON), POWER MOSFET, 150V SINGLE N CHAN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
