NTMFS005P03P8ZT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET P-CH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS005P03P8ZT1G Specifications:
- MfrPart.: NTMFS005P03P8ZT1G
- Mfr: onsemi
- Description: MOSFET P-CH
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 15.3A (Ta), 164A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.7mOhm @ 22A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 112 nC @ 4.5 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 7880 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 900mW (Ta), 104W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS005P03P8ZT1G onsemi (ON), MOSFET P-CH, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMFS005P03P8ZT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
