NTMFS005N10MCLT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: SINGLE N-CHANNEL POWER MOSFET 10
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS005N10MCLT1G Specifications:
- MfrPart.: NTMFS005N10MCLT1G
- Mfr: onsemi
- Description: SINGLE N-CHANNEL POWER MOSFET 10
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 16A (Ta), 105A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5.1mOhm @ 34A, 10V
- Vgs(th)(Max)@Id: 3V @ 192µA
- GateCharge(Qg)(Max)@Vgs: 55 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4100 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 125W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS005N10MCLT1G onsemi (ON), SINGLE N-CHANNEL POWER MOSFET 10, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
