NTMFD2D4N03P8 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerWDFN
- Description: MOSFET 2N-CH 30V 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFD2D4N03P8 Specifications:
- MfrPart.: NTMFD2D4N03P8
- Mfr: onsemi
- Description: MOSFET 2N-CH 30V 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Dual) Asymmetrical
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 30V
- Current-ContinuousDrain(Id)@25°C: 17A (Ta), 56A (Tc), 25A (Ta), 84A (Tc)
- RdsOn(Max)@IdVgs: 5mOhm @ 17A, 10V, 2.4mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA, 3V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 24nC, 55nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 1715pF @ 15V, 3825pF @ 15V
- Power-Max: 1W (Ta), 23W (Tc), 1.1W (Ta), 25W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerWDFN
- NTMFD2D4N03P8 onsemi (ON), MOSFET 2N-CH 30V 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
NTMFD2D4N03P8, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
