NTMFD1D4N02P1E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerWDFN
- Description: MOSFET N-CH 20V 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFD1D4N02P1E Specifications:
- MfrPart.: NTMFD1D4N02P1E
- Mfr: onsemi
- Description: MOSFET N-CH 20V 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Dual) Asymmetrical
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 25V
- Current-ContinuousDrain(Id)@25°C: 13A (Ta), 74A (Tc), 24A (Ta), 155A (Tc)
- RdsOn(Max)@IdVgs: 3.3mOhm @ 20A, 10V, 1.1mOhm @ 37A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA, 2V @ 800µA
- GateCharge(Qg)(Max)@Vgs: 7.2nC @ 4.5V, 21.5nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 1180pF @ 13V, 3603pF @ 13V
- Power-Max: 960mW (Ta), 1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerWDFN
- NTMFD1D4N02P1E onsemi (ON), MOSFET N-CH 20V 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
NTMFD1D4N02P1E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
