NTLJS3D0N02P8ZTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-PQFN (2x2)
- Description: MOSFET N-CH 20V 12.1A 6PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTLJS3D0N02P8ZTAG Specifications:
- MfrPart.: NTLJS3D0N02P8ZTAG
- Mfr: onsemi
- Description: MOSFET N-CH 20V 12.1A 6PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 12.1A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 3.8mOhm @ 10A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 2165 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 860mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-PQFN (2x2)
- NTLJS3D0N02P8ZTAG onsemi (ON), MOSFET N-CH 20V 12.1A 6PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTLJS3D0N02P8ZTAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
