NTLJS3113PT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-WDFN (2x2)
- Description: MOSFET P-CH 20V 3.5A 6WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTLJS3113PT1G Specifications:
- MfrPart.: NTLJS3113PT1G
- Mfr: onsemi
- Description: MOSFET P-CH 20V 3.5A 6WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: µCool™
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.5V, 4.5V
- RdsOn(Max)@IdVgs: 40mOhm @ 3A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 15.7 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 1329 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 700mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-WDFN (2x2)
- NTLJS3113PT1G onsemi (ON), MOSFET P-CH 20V 3.5A 6WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
