NTL4502NT1 onsemi N-CHANNEL POWER MOSFET
NTL4502NT1 Images
NTL4502NT1 Images
NTL4502NT1
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 16-PowerQFN
  • Description: N-CHANNEL POWER MOSFET
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NTL4502NT1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NTL4502NT1 Specifications:
  • MfrPart.: NTL4502NT1
  • Mfr: onsemi
  • Description: N-CHANNEL POWER MOSFET
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • FETType: 4 N-Channel (H-Bridge)
  • FETFeature: Logic Level Gate
  • DraintoSourceVoltage(Vdss): 24V
  • Current-ContinuousDrain(Id)@25°C: 11.4A
  • RdsOn(Max)@IdVgs: 11mOhm @ 15A, 10V
  • Vgs(th)(Max)@Id: 2V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 13nC @ 4.5V
  • InputCapacitance(Ciss)(Max)@Vds: 1605pF @ 20V
  • Power-Max: 1.7W
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 16-PowerQFN
  • NTL4502NT1 onsemi (ON), N-CHANNEL POWER MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
