NTHS5404T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ChipFET™
- Description: MOSFET N-CH 20V 5.2A CHIPFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTHS5404T1G Specifications:
- MfrPart.: NTHS5404T1G
- Mfr: onsemi
- Description: MOSFET N-CH 20V 5.2A CHIPFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 5.2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 30mOhm @ 5.2A, 4.5V
- Vgs(th)(Max)@Id: 600mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 1.3W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: ChipFET™
- NTHS5404T1G onsemi (ON), MOSFET N-CH 20V 5.2A CHIPFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTHS5404T1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
