NTHD3101FT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ChipFET™
- Description: MOSFET P-CH 20V 3.2A CHIPFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTHD3101FT1G Specifications:
- MfrPart.: NTHD3101FT1G
- Mfr: onsemi
- Description: MOSFET P-CH 20V 3.2A CHIPFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.2A (Tj)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 80mOhm @ 3.2A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7.4 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 680 pF @ 10 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 1.1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: ChipFET™
- NTHD3101FT1G onsemi (ON), MOSFET P-CH 20V 3.2A CHIPFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTHD3101FT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
