NTHC5513T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SMD, Flat Lead
- Description: MOSFET N/P-CH 20V CHIPFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTHC5513T1G Specifications:
- MfrPart.: NTHC5513T1G
- Mfr: onsemi
- Description: MOSFET N/P-CH 20V CHIPFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N and P-Channel
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 2.9A, 2.2A
- RdsOn(Max)@IdVgs: 80mOhm @ 2.9A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 4nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 180pF @ 10V
- Power-Max: 1.1W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SMD, Flat Lead
- NTHC5513T1G onsemi (ON), MOSFET N/P-CH 20V CHIPFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
NTHC5513T1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
