NTGS5120PT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-TSOP
- Description: MOSFET P-CH 60V 1.8A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTGS5120PT1G Specifications:
- MfrPart.: NTGS5120PT1G
- Mfr: onsemi
- Description: MOSFET P-CH 60V 1.8A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 1.8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 111mOhm @ 2.9A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18.1 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 942 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 600mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-TSOP
- NTGS5120PT1G onsemi (ON), MOSFET P-CH 60V 1.8A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
