NTGS1135PT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-TSOP
- Description: MOSFET P-CH 8V 4.6A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTGS1135PT1G Specifications:
- MfrPart.: NTGS1135PT1G
- Mfr: onsemi
- Description: MOSFET P-CH 8V 4.6A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 8 V
- Current-ContinuousDrain(Id)@25°C: 4.6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.2V, 4.5V
- RdsOn(Max)@IdVgs: 31mOhm @ 4.6A, 4.5V
- Vgs(th)(Max)@Id: 850mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 4.5 V
- Vgs(Max): ±6V
- InputCapacitance(Ciss)(Max)@Vds: 2200 pF @ 6 V
- FETFeature: -
- PowerDissipation(Max): 970mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-TSOP
- NTGS1135PT1G onsemi (ON), MOSFET P-CH 8V 4.6A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
