NTF5P03T3G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223 (TO-261)
- Description: MOSFET P-CH 30V 3.7A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTF5P03T3G Specifications:
- MfrPart.: NTF5P03T3G
- Mfr: onsemi
- Description: MOSFET P-CH 30V 3.7A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 3.7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 100mOhm @ 5.2A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 38 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 950 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.56W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223 (TO-261)
- NTF5P03T3G onsemi (ON), MOSFET P-CH 30V 3.7A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
