NTF3055-100T1G-IRH1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223 (TO-261)
- Description: MOSFET N-CH 60V 3A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTF3055-100T1G-IRH1 Specifications:
- MfrPart.: NTF3055-100T1G-IRH1
- Mfr: onsemi
- Description: MOSFET N-CH 60V 3A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 3A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 110mOhm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 455 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.3W (Ta)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223 (TO-261)
- NTF3055-100T1G-IRH1 onsemi (ON), MOSFET N-CH 60V 3A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTF3055-100T1G-IRH1, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
