NTD78N03T4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 25V 11.4A/78A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD78N03T4G Specifications:
- MfrPart.: NTD78N03T4G
- Mfr: onsemi
- Description: MOSFET N-CH 25V 11.4A/78A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 11.4A (Ta), 78A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6mOhm @ 78A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2.25 pF @ 12 V
- FETFeature: -
- PowerDissipation(Max): 1.4W (Ta), 64W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD78N03T4G onsemi (ON), MOSFET N-CH 25V 11.4A/78A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
