NTD5802NT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 40V 16.4A/101A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD5802NT4G Specifications:
- MfrPart.: NTD5802NT4G
- Mfr: onsemi
- Description: MOSFET N-CH 40V 16.4A/101A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 16.4A (Ta), 101A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 4.4mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 100 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5025 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 93.75W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD5802NT4G onsemi (ON), MOSFET N-CH 40V 16.4A/101A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTD5802NT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
