NTD5406NT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 40V 12.2A/70A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD5406NT4G Specifications:
- MfrPart.: NTD5406NT4G
- Mfr: onsemi
- Description: MOSFET N-CH 40V 12.2A/70A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 12.2A (Ta), 70A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 10mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 45 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2500 pF @ 32 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 100W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD5406NT4G onsemi (ON), MOSFET N-CH 40V 12.2A/70A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
