NTD40N03RG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 25V 7.8A/32A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD40N03RG Specifications:
- MfrPart.: NTD40N03RG
- Mfr: onsemi
- Description: MOSFET N-CH 25V 7.8A/32A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 7.8A (Ta), 32A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 16.5mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 5.78 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 584 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 1.5W (Ta), 50W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD40N03RG onsemi (ON), MOSFET N-CH 25V 7.8A/32A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTD40N03RG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
