NTD3808NT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 16V 12A/76A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD3808NT4G Specifications:
- MfrPart.: NTD3808NT4G
- Mfr: onsemi
- Description: MOSFET N-CH 16V 12A/76A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 16 V
- Current-ContinuousDrain(Id)@25°C: 12A (Ta), 76A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5.8mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 1.66 pF @ 12 V
- FETFeature: -
- PowerDissipation(Max): 1.3W (Ta), 52W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD3808NT4G onsemi (ON), MOSFET N-CH 16V 12A/76A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTD3808NT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
