NTD25P03L1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET P-CH 30V 25A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD25P03L1G Specifications:
- MfrPart.: NTD25P03L1G
- Mfr: onsemi
- Description: MOSFET P-CH 30V 25A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 25A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 5V
- RdsOn(Max)@IdVgs: 80mOhm @ 25A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 5 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 1.26 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 75W (Tj)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- NTD25P03L1G onsemi (ON), MOSFET P-CH 30V 25A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
