NTD15N06L-001 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 60V 15A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD15N06L-001 Specifications:
- MfrPart.: NTD15N06L-001
- Mfr: onsemi
- Description: MOSFET N-CH 60V 15A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 15A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 100mOhm @ 7.5A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 5 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 440 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.5W (Ta), 48W (Tj)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- NTD15N06L-001 onsemi (ON), MOSFET N-CH 60V 15A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
