NTD14N03RG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 25V 2.5A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD14N03RG Specifications:
- MfrPart.: NTD14N03RG
- Mfr: onsemi
- Description: MOSFET N-CH 25V 2.5A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 95mOhm @ 5A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 1.8 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 115 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 1.04W (Ta), 20.8W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD14N03RG onsemi (ON), MOSFET N-CH 25V 2.5A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
