NTD12N10G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 100V 12A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD12N10G Specifications:
- MfrPart.: NTD12N10G
- Mfr: onsemi
- Description: MOSFET N-CH 100V 12A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 12A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 165mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 550 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.28W (Ta), 56.6W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD12N10G onsemi (ON), MOSFET N-CH 100V 12A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTD12N10G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
