NTBGS4D1N15MC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK (TO-263)
- Description: MOSFET N-CH 150V 20A/185A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTBGS4D1N15MC Specifications:
- MfrPart.: NTBGS4D1N15MC
- Mfr: onsemi
- Description: MOSFET N-CH 150V 20A/185A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 20A (Ta), 185A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 8V, 10V
- RdsOn(Max)@IdVgs: 4.1mOhm @ 104A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 574µA
- GateCharge(Qg)(Max)@Vgs: 88.9 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7285 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 3.7W (Ta), 316W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK (TO-263)
- NTBGS4D1N15MC onsemi (ON), MOSFET N-CH 150V 20A/185A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTBGS4D1N15MC, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
