NTBGS3D5N06C Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK-7
- Description: POWER MOSFET, 60 V, 3.7 M?, 127A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTBGS3D5N06C Specifications:
- MfrPart.: NTBGS3D5N06C
- Mfr: onsemi
- Description: POWER MOSFET, 60 V, 3.7 M?, 127A
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 22A (Ta), 127A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V, 12V
- RdsOn(Max)@IdVgs: 3.7mOhm @ 24A, 12V
- Vgs(th)(Max)@Id: 4V @ 122µA
- GateCharge(Qg)(Max)@Vgs: 39 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2430 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 3.7W (Ta), 115W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK-7
- NTBGS3D5N06C onsemi (ON), POWER MOSFET, 60 V, 3.7 M?, 127A, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTBGS3D5N06C, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
