NTBG160N120SC1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK-7
- Description: TRANS SJT N-CH 1200V 19.5A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTBG160N120SC1 Specifications:
- MfrPart.: NTBG160N120SC1
- Mfr: onsemi
- Description: TRANS SJT N-CH 1200V 19.5A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 19.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 224mOhm @ 12A, 20V
- Vgs(th)(Max)@Id: 4.3V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 33.8 nC @ 20 V
- Vgs(Max): +25V, -15V
- InputCapacitance(Ciss)(Max)@Vds: 678 pF @ 800 V
- FETFeature: -
- PowerDissipation(Max): 136W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK-7
- NTBG160N120SC1 onsemi (ON), TRANS SJT N-CH 1200V 19.5A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTBG160N120SC1, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
