NTB85N03G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 28V 85A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTB85N03G Specifications:
- MfrPart.: NTB85N03G
- Mfr: onsemi
- Description: MOSFET N-CH 28V 85A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 28 V
- Current-ContinuousDrain(Id)@25°C: 85A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6.8mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 29 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2150 pF @ 24 V
- FETFeature: -
- PowerDissipation(Max): 80W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- NTB85N03G onsemi (ON), MOSFET N-CH 28V 85A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTB85N03G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
