NTB5605PT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET P-CH 60V 18.5A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTB5605PT4G Specifications:
- MfrPart.: NTB5605PT4G
- Mfr: onsemi
- Description: MOSFET P-CH 60V 18.5A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 18.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 140mOhm @ 8.5A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1190 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 88W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- NTB5605PT4G onsemi (ON), MOSFET P-CH 60V 18.5A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTB5605PT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
