NTB25P06 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET P-CH 60V 27.5A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTB25P06 Specifications:
- MfrPart.: NTB25P06
- Mfr: onsemi
- Description: MOSFET P-CH 60V 27.5A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 27.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 82mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 50 nC @ 10 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 1680 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 120W (Tj)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- NTB25P06 onsemi (ON), MOSFET P-CH 60V 27.5A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTB25P06, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
