NSVMUN5236T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased Package/Case: SC-70, SOT-323
- Description: TRANS PREBIAS NPN 50V SC70-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSVMUN5236T1G Specifications:
- MfrPart.: NSVMUN5236T1G
- Mfr: onsemi
- Description: TRANS PREBIAS NPN 50V SC70-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- TransistorType: NPN - Pre-Biased
- Current-Collector(Ic)(Max): 100 mA
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- Resistor-Base(R1): 100 kOhms
- Resistor-EmitterBase(R2): 100 kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 80 @ 5mA, 10V
- VceSaturation(Max)@IbIc: 250mV @ 300µA, 10mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 202 mW
- MountingType: Surface Mount
- Package/Case: SC-70, SOT-323
- NSVMUN5236T1G onsemi (ON), TRANS PREBIAS NPN 50V SC70-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
NSVMUN5236T1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
