NSVBC143ZPDXV6T5G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SOT-563, SOT-666
- Description: TRANS PREBIAS NPN/PNP 50V SOT563
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSVBC143ZPDXV6T5G Specifications:
- MfrPart.: NSVBC143ZPDXV6T5G
- Mfr: onsemi
- Description: TRANS PREBIAS NPN/PNP 50V SOT563
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- TransistorType: 1 NPN, 1 PNP - Pre-Biased (Dual)
- Current-Collector(Ic)(Max): 100mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- Resistor-Base(R1): 4.7kOhms
- Resistor-EmitterBase(R2): 47kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 80 @ 5mA, 10V
- VceSaturation(Max)@IbIc: 250mV @ 1mA, 10mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 500mW
- MountingType: Surface Mount
- Package/Case: SOT-563, SOT-666
- NSVBC143ZPDXV6T5G onsemi (ON), TRANS PREBIAS NPN/PNP 50V SOT563, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
NSVBC143ZPDXV6T5G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
